TP Power 4090 Motor
TP Power 4090 Motor
SKU:TP-4090-1812KV-CM
Low stock
Couldn't load pickup availability
This is a custom made motor recommended by our top drivers.
This motor reached 198MPH in a Perfect Pass RC 1/7 Car (single).
⚙️MOTOR SPECIFICATIONS
| 4090 1812KV CM (8S) | |
|---|---|
| Can | Smooth |
| Wind | D |
| KV | 1812 |
| Max Amps (A) | 420 |
| Max Volt (V) | 8S |
| Continuous Power (W) | 7000 |
| Max Power (W) | 13000 |
| Max RPM | 55K |
| Internal Resistance (Ohm) | 0.0028 |
| No-load Current (A) | 4.0 |
| Shaft Diameter (mm) | 8 |
| Shaft Length (mm) | 24 |
| Diameter X Length (mm) | 40X127 |
| Mounting Pattern | 4 sets of M3 & M4 screw holes on the same front plate; with 25mm diagonal distance. |
| Weight | 820g |
| Pole | 4 |
| 4090 1620KV SVM (8S) | |
|---|---|
| Can | Smooth |
| Wind | D |
| KV | 1620 |
| Max Amps (A) | 392 |
| Max Volt (V) | 8S |
| Continuous Power (W) | 7200 |
| Max Power (W) | 13300 |
| Max RPM | 55K |
| Internal Resistance (Ohm) | 0.0028 |
| No-load Current (A) | 5.2 |
| Shaft Diameter (mm) | 8 |
| Shaft Length (mm) | 24 |
| Diameter X Length (mm) | 40X127 |
| Mounting Pattern | 4 sets of M3 & M4 screw holes on the same front plate; with 25mm diagonal distance. |
| Weight | 850g |
| Pole | 4 |
This motor is absolutely epic. Love it!!
I’m building an Arrma infraction GT chassis my goal is a 180mph. My question is this motor capable of that? Also what ESC would you recommend? if I gear down, can I still bash with this motor?
Hey Yazan,
Yes, this motor has been used in signle motor builds way over 180.
I would recommend the C5A ESC to go with it.
You can still bash with it, but make sure you use lower gears when bashing.
Hello, i am wondering if the tp 4090svm 1620kv comes sensored or not, thank you
Hey,
No, it is sensorless.
I just recently bought a TP motor from you it's the 4090 series 1620 KV I thought it was censored yet I see no sense or wire?
While it is possible to have a sensor added to any TP motor, we only stock the sensorless versions.
Will the tp 4090 fit on the felony in the stock motor position?
No, it is too long to fit that way.
